1.4GHz 3ft Dish Antenna

Model

ANT1400D21P-MIMO

Electrical

Frequency Range

1400-1500MHz

Gain

21±1dBi

Polarization

Dual Slant (±45° or V/H)

Horizontal  Beam width

20°type

Vertical  Beam width

20°type

Front-To-Back Ratio

>20dB

Port To Port Isolation

>20dB

Cross Polarization

20 dB type

VSWR

<1.5 type

Maximum Power Per Port

50 watts

Impedance

50 ohms

Lightning Protection

DC ground

Mechanical

Antenna Size

φ0.9 m

Weight

13 kg

Antenna Color

white

Reflector Material

Aluminum

Connector Type and Location

2 x N- Female

Operational Temperature

-45°C to 65°C

Mount

Pole (D30-80mm)

Mechanical Downtilt

-15° to 15°

Humidity

ETS 300 019-1-4, EN 302 085(ANNEX A.1.1)
