Electrical

Model

ANT1742D25PA-XP

Frequency Range

1710-2690MHz

3300-4200MHz

Gain( dBi)

23±1dBi

25±1dBi

VSWR

<2.0

<2.0

Horizontal Beam width

10±5°

7±3°

Vertical Beam width

10±5°

7±3°

Polarization

Dual Slant (±45°)

Isolation

25dB

Front to Back Ratio

>30dB

Maximum Power Per Port

50W

Impedance

50Ω

Lighting protection

DC Ground

Mechanical

Connector

2-RPSMA/N Male/N Female

Antenna Size

φ0.9 m

Antenna Weight

13kg

Antenna color

white

Diameter of the Pole

Φ30 to φ70 mm

Mechanical Tilt

± 20°

Operational Temperature

-40°C to +70°C (-32°F to +158°F)
