1.7-4.2GHz 22dBi Dish Antenn

Technical Specifications

  Electrical

  Model

ANT1742D22PA-XP

  Frequency Range

1710-2690MHz

3300-4200MHz

  Gain( dBi)

20±1dBi

22±1dBi

  VSWR

<2.0

<2.0

  Horizontal Beam width

15±5°

12±5°

  Vertical Beam width

15±5°

12±5°

  Polarization

Dual Slant (±45°)

  Isolation

25dB

  Front to Back Ratio

>25dB

  Maximum Power Per Port

50W

  Impedance

50Ω

  Lighting protection

DC Ground

  Mechanical

  Connector

2-RPSMA/N Male/N Female

  Antenna Size

φ0.6 m

  Antenna Weight

5.5kg

  Antenna color

white

  Diameter of the Pole

Φ30mm to φ70 mm

  Mechanical Tilt

± 20°

  Operational Temperature

-40°C to +70°C (-32°F to +158°F)
